Raw Mill

【Feeding size】：≤25mm

【Discharging size】：0.074mm-0.4mm

【Application】：Metallurgy industry, Chemical industry, and Power industry and so on

Introduction
Principle
Parameters

Raw mill is mainly used in grinding raw materials and end products in cement plant. It is also suitable for various ores and other materials metallurgy, mine, chemical and construction. Besides, it has two forms of milling, one is an open form, and the other is a recycle close form equipped with powder concentrator. It is widely applied in many industries and has convenient operation.

Feature of Raw mill
1. Strong adaptability;
2. Continuous production;
3. Large crushing ration;
4. Easy to adjust the output product's size.

Wet Raw Mill

Specification (Dia×Length)	Rotating speed (r/min)	Feed size (mm)	Capacity (t/h)	Grinding media load (t)	Main motor			Main reducer		Weight(t)
Specification (Dia×Length)	Rotating speed (r/min)	Feed size (mm)	Capacity (t/h)	Grinding media load (t)	Model	Power(kw)	Rotating speed (r.p.m)	Model	Reduction ratio	Weight(t)
φ2.2×7	21.4	≤3	20～25	31	YR148-8	380	740	ZD70-9	5	49
φ2.2×13	21.6	≤25	33～37	58～60	YR630-8/1180	630	740	MBY630	5.6	53.4
φ2.4×13	21	≤25	45～50	65～70	YR800-8/1180	800	740	JDX710	5.6	131
φ2.6×13	20	≤25	45～46	80t(max)	YR1000-8/1180	1000	740	TDX800	6.3	153
φ6.2×6.4	18.5	≤25	32～41	86～90.5	TDMK1000-36	1000	740			134

Dry Raw Mill

Specification (Dia×Length)	Rotating speed (r/min)	Feed size (mm)	Capacity (t/h)	Grinding media load (t)	Main motor			Main reducer		Weight(t)
Specification (Dia×Length)	Rotating speed (r/min)	Feed size (mm)	Capacity (t/h)	Grinding media load (t)	Model	Power(kw)	Rotating speed (r.p.m)	Model	Reduction ratio	Weight(t)
φ2.4×8	20.91	≤25	25～28	39～42	JRQ1512-8	570	740	ZD80-9	5	76.4
φ2.4×10	20	≤25	Open circuit 27～30 Closed circuit 38～40	50	YR710-8/1180	710	740	JDX630	5.6	111
φ2.4×11	21	≤25	Open circuit 41～42 Closed circuit 46～48	62～65	YR800-8/1180	800	740	MBY710	6.3	125
φ2.4×12	21	≤25	Open circuit 40～42 Closed circuit 45～48	63～65	YR800-8/1180	800	740	MBY710	6.3	127
φ2.4×13	21.5	≤25	48～51	68～72	YR800-8/1180	800	740	MBY710	6.3	131
φ2.6×8	20	≤25	30～35	54	YR630-8/1180	630	740	JDX630	5.6	135
φ2.6×10	20.91	≤25	45～46	80	YR1000-8/1180	1000	740	JDX710	6.3	136
φ3×9	19.13	≤25	50～55	76～80	YR1000-8/1180	1000	740	JDX800	6.3	145
φ3.2×7	18.25	≤25	50～52	58	YR1000-8/1180	1000	740	MBY800	6.3	140
φ3.2×9	18.3	≤25	60～70	90	YR1250-8/1430	1250	740	JDX900	7.1	175
φ4.6×10+3.5	15	≤25	195	190		3550	740	JS150-B-F		476
